Road frameset RIDLEY HELIUM DISC - color HED-01As (Black-White-Merlot Pearl)

The Helium Disc performance road bike contains all the unprecedented cycling qualities and superb technology that go into the top-of-the-line Helium SLX Disc, but with a much lower price tag. The Helium Disc road bike incorporates the unique oval tube shape which perfectly balances stiffness, weight and comfort. In addition, all cables are fully integrated in the Helium thanks to the F-Steerer technology. This gives it a clean look that's maintenance-free. What you'll feel is how light, reactive, stiff and comfortable it is to ride - from first to last pedal stroke.

• use of high modulus carbon to save weight without reducing stiffness
• oversized round tube shape offer the best stiffness to weight ratio
• use of 12 mm thru-axle increased the frame’s stiffness
• specially designed oversized PF30 bottom bracket offers a very high level of stiffness for maximal power transfer
• tapered 1 1/8 - 1 1/4 head tube with angular contact bearings
• flex seat stays provide comfort without sacrificing stiffness
• straight blade fork adds to that sublime handling taking hairpin bends
• aerodynamically optimized by using F-Steerer technology - every cable can be integrated to create a clean cockpit
• compatibile with flatmount discbrakes
• compatible with electronic and mechanical shifting

HELIUM DISC	XXS	XS	S	M	L	XL
A - MAX. SADDLE HEIGHT	740	770	800	830	860	890
B - SEAT TUBE, CENTER-TOP	450	480	510	540	570	600
C - TOP TUBE, HORIZONTAL	515	525	545	565	585	600
D - HEAD TUBE LENGTH	110	130	145	175	205	230
E - SEAT TUBE ANGLE	75,0	74,0	73,5	73,0	72,5	72,5
F - HEAD TUBE ANGLE	71,8	72,0	73,0	73,5	73,5	74,0
G - CHAINSTAY LENGTH	405	405	405	405	408	408
H - BB DROP	68	68	66	66	63	63
I - WHEELBASE	970	970	977	987	1005	1014
J - STANDOVER HEIGHT	721	755	775	804	834	861
S - STACK	507	527	542	573	599	624
R - REACH	374	379	384	390	396	403
