Cyclocross bicycle RIDLEY X-RIDE DISC - GRX800 2x11s - configurator
- From weekend warriors to those who need a backup bike, the premium alloy-framed X-Ride delivers via Ridley’s race-proven geometry, internal cable routing, and shaped seatstays that damp energy-sapping vibrations.
*rzeczywista specyfikacja produktu może różnić się od przedstawionej na zdjęciu. Prosimy o zapoznanie się z dokładną specyfikacją poniżej.
Cyclocross bikes often pull double-duty: as a race bike, a commuter, training – whatever. But a thoroughbred like the X-ride is fantastic as a primary race bike or pit bike in your quiver. From weekend warriors to those who need a backup bike, the premium alloy-framed X-Ride delivers via Ridley’s race-proven geometry, internal cable routing, and shaped seatstays that damp energy-sapping vibrations.
- 1.5” oversized lower head tube bearing and fork crown for superior control and stiffness
- tapered 1-1/8 1-1/2 headtube with angular contact bearings
- internal cable routing
- mudless tube technology on front fork and seat stays
- S-Bend seat stays provide additional comfort and increased tire clearance
- compatibile with flatmount disc brakes
- 12mm TA adds extra stiffness to the frame/wheel connection
| X-RIDE DISC |
XXS | XS | S | M | L | XL |  |
|---|---|---|---|---|---|---|---|
| A - MAX. SADDLE HEIGHT |
745 | 770 | 795 | 820 | 845 | 870 | |
| B - SEAT TUBE, CENTER-TOP | 450 | 475 | 500 | 525 | 550 | 575 | |
| C - TOP TUBE, HORIZONTAL |
503 | 511 | 523 | 532 | 548 | 563 | |
| D - HEAD TUBE LENGTH | 89 | 100 | 115 | 135 | 155 | 180 | |
| E - SEAT TUBE ANGLE | 75,0 | 74,5 | 74,0 | 73,5 | 73,5 | 73,5 | |
| F - HEAD TUBE ANGLE | 71,5 | 72,0 | 72,0 | 72,0 | 72,0 | 72,0 | |
| G - CHAINSTAY LENGTH | 425 | 425 | 425 | 425 | 425 | 425 | |
| H - BB DROP | 53 | 57 | 60 | 62 | 64 | 64 | |
| I - WHEELBASE | 1000 | 1000 | 1004 | 1009 | 1023 | 1039 | |
| J - STANDOVER HEIGHT | 735 | 751 | 768 | 789 | 809 | 833 | |
| S - STACK | 496 |
512 | 529 | 550 | 571 | 595 | |
| R - REACH | 382 | 382 | 383 | 384 | 391 | 399 |
All RIDLEY frames are warranted by Producer against manufacturing defects in material and/or workmanship for 5 years of the original owner if the frame is purchased from an Authorized Ridley Dealer who perform warranty checkup before sale what is confirmed with a proper receipt/invoice. Frame must be registered within one month after purchase at at Producer website www.ridley-bikes.com/register-ridley
In case of complete bicycles components are warranted separate by specific producer (usually for 2 years).
Future service, maintenance and repairs should be performed according to your knowledge and skills by yourself or by an Authorized Ridley Dealer, or in case of lack of a one in you area at preferred professional bicycle workshop.
Please contact us if any further instructions are needed.
