Road frameset RIDLEY NOAH DISC - configurator
New in

Road frameset RIDLEY NOAH DISC - configurator

  • The Noah Disc is all about speed and performance. So, if you're all about speed, in search of the ultimate racing monster that doesn't break the bank, the Noah Disc road bike is the only one for you.
3 953,00 €
incl. VAT / piece
Lowest price in 30 days before discount: / piece
Regular price: / piece
Before we process the order with this product, the prepayment in the amount of 988,00 €. may be required. Detailed information will be provided in the order summary, before its placement.
Availaible on request
Availaible on request
14 days for free returns
This product is not available in a stationary store
Safe shopping
Size
Color
Cockpit
Seatpost

*rzeczywista specyfikacja produktu może różnić się od przedstawionej na zdjęciu. Prosimy o zapoznanie się z dokładną specyfikacją poniżej.

The Noah Disc is all about speed and performance. It’s racing heritage, combined with superior aerodynamic technology and beautiful design sets a new benchmark in the aero category. The Noah Disc has all the same technologies and ride qualities of its big brother, the Noah Fast Disc - Champ Caleb Ewan's favorite road bike, but is more budget-friendly. So, if you're all about speed, in search of the ultimate racing monster that doesn't break the bank, the Noah Disc road bike is the only one for you.

  • F-Tubing is our droplet-shaped tubing which significantly minimizes wind drag
  • F-Surface Plus is the application of a textured surface in strategic locations for decreased wind drag
  • F-Steerer ingeniously allows for fully internal cabling
  • full carbon tapered 1-1/8 1-1/2 head tube with angular contact bearings
  • internally routed cabling to minimize airflow disturbance
  • oversized PF30 bottom bracket and aero down tube
  • compatible with electronic and mechanical shifting
  • compatible with disc brakes
NOAH DISC XXS XS S M L XL Geometry-Road
A - MAX. SADDLE HEIGHT 720 750 775 800 825 850
B - SEAT TUBE, CENTER-TOP 430 455 480 505 530 555
C - TOP TUBE, HORIZONTAL 512 526 545 565 587 603
D - HEAD TUBE LENGTH 95 117 140 164 194 218
E - SEAT TUBE ANGLE 74,5 74,0 73,5 73,0 72,5 72,5
F - HEAD TUBE ANGLE 71,5 72,0 73,0 73,5 73,5 74,0
G - CHAINSTAY LENGTH 405 405 405 405 408 408
H - BB DROP 68 68 66 66 63 63
I - WHEELBASE 969 975 977 987 1007 1017
J - STANDOVER HEIGHT 738 754 775 799 830 860
S - STACK 493 516 541 565 591 616
R - REACH 375 378 385 393 401 409
Brand
Series
FRAMESET SPECIFICATIONS (SET INCLUDES):
Frame
Noah Disc, 30-24T HM UD Carbon, F-Tubing, F-Surface Plus, F-Steerer, TA 12x142mm
Frame material
carbon
Frame weight (at size M)
1150 g
Fork
Noah Disc, 30T-24T HM UD Carbon, F-Surface, TA 12x100mm
Headset
FSA 1 1/8 x 1 1/2 integrated
Wheel axles
F TA12x100
R TA12x142
Saddle clamp
integrated
COMPATIBILITY:
Front derailleur
Braze-On type
BB
PF30 standard (Press-Fit 30)
Brakes
F140/160mm FlatMount
R140/160mm FlatMount
To download
RIDLEY [5 years]

All RIDLEY frames are warranted by Producer against manufacturing defects in material and/or workmanship for 5 years of the original owner if the frame is purchased from an Authorized Ridley Dealer who perform warranty checkup before sale what is confirmed with a proper receipt/invoice. Frame must be registered within one month after purchase at at Producer website www.ridley-bikes.com/register-ridley
In case of complete bicycles components are warranted separate by specific producer (usually for 2 years).

Future service, maintenance and repairs should be performed according to your knowledge and skills by yourself or by an Authorized Ridley Dealer, or in case of lack of a one in you area at preferred professional bicycle workshop.
